Grundfos SCALA2 3-45 Compact Self Priming Booster With Integrated Speed Control

Free Shipping Australia Wide!

GRUNDFOS SCALA2 is a robust, composite, variable speed pump that adjusts performance according to water
demand, providing constant pressure to all taps. The fully integrated pump includes a motor, tank, sensor, drive
and non-return valve in one compact unit that is quick and easy to install.
The SCALA2 is self-priming, allowing for use from both above and below ground water sources and the watercooled
motor ensures quiet operation.
Liquid temperature: 0°C-+45°C
Ambient temperature: 0°C-+55°C
Supply voltage: 1 x 240 Volt 50 Hz
Adjustable constant pressure: Min 1.5 bar/max 4 bar
Maximum inlet pressure: 6 bar- 1.5 bar required to reach 5.5 bar
Nominal flow: 3 m3/h (3-4 taps)
Enclosure class: Suitable for outdoor installation (IP X4D)
Scope of delivery: Non return valves (inlet/outlet), cable 2 m with plug
Noise pressure level: Low noise levels (47 dB(A))

Constant pressure = constant comfort, same pressure
maintained whatever the demand
• Compact and easy to install: inlet and outlet
connections flexible ± 5°
• Easy to select: 1 single model dedicated to domestic
applications
• Self priming booster: Able to lift water from a depth of
up to 8 m (with foot valve) in less than 5 minutes
• High levels of integrated protections to protect your
investment
• Efficient and quiet: permanent
